FRONT AXLE

L3560, L4060, L4760, L5060, L5460, L6060, WSM

6-S4

3. TIGHTENING TORQUES

Tightening torques of screws, bolts and nuts on the table below are especially specified.

(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)

9Y1210824FAS0004US0

Item

N·m

kgf·m

lbf·ft

Tie-rod lock nut

167 to 196

17.0 to 20.0

123 to 144

Front axle pivot lock nut

59 to 98

6.0 to 10

44 to 72

Power steering hose retaining nut

25 to 29

2.5 to 3.0

18 to 21

Cylinder cover mounting screw

61 to 70

6.2 to 7.2

45 to 52

Front wheel mounting nut

137

14.0

101

Bracket mounting screw and nut

(L3560, L4060, L4760 and L5060)

78 to 90

7.9 to 9.2

58 to 66

Bracket mounting screw and nut

(L5460 and L6060)

103 to 117

10.5 to 12.0

76.0 to 86.7

Tie-rod end nut (L3560 and L4060)

40 to 45

4.0 to 4.6

29 to 33

Tie-rod end nut

(L4760, L5060, L5460 and L6060)

157 to 176

16.0 to 18.0

116 to 130

Bevel gear case mounting screw (L3560)

124 to 147

12.6 to 15.0

91.2 to 108

Bevel gear case mounting screw

(L4060, L4760, L5060, L5460 and L6060)

167 to 196

17.0 to 20.0

123 to 144

Axle flange mounting screw and nut

(L3560 and L4060)

24 to 27

2.4 to 2.8

18 to 20

Axle flange mounting screw and nut

(L4760, L5060, L5460 and L6060)

30 to 34

3.0 to 3.5

22 to 25

Axle case support mounting screw

128 to 142

13.0 to 14.5

94.1 to 104

Tie-rod joint to steering cylinder

167 to 196

17.0 to 20.0

123 to 144

Differential case cover mounting screw

(L3560 and L4060)

48 to 58

4.9 to 6.0

36 to 43

Differential case cover mounting screw

(L4760, L5060, L5460 and L6060)

61 to 70

6.2 to 7.2

45 to 52

KiSC issued 03, 2016 A
