STEERING

L3560, L4060, L4760, L5060, L5460, L6060, WSM

7-S1

1. TROUBLESHOOTING

9Y1210824STS0001US0

Symptom

Probable Cause

Solution

Reference

Page

Tractor Can Not Be
Steered

Steering controller broken

Replace

Steering linkage broken

Replace

Pipe broken

Replace

–

Front Wheels Vibrate

Improper toe-in adjustment

Adjust

6-S5

Air in the hydraulic system

Bleed

Improperly mounted wheels

Replace

7-S7

Tie-rod end loose or worn

Retighten or replace

7-S7

Clearance between front axle center pivots and

bracket bushing excessive

Replace

6-S19

Steering controller malfunctioning

Replace

Hard Steering

Steering linkage bushings sticking

Replace

–

Hydraulic pump malfunctioning

Replace

8-S14

Overload

–

Transmission fluid improper or insufficient

Change or fill

G-9

Oil leak from pipe joint

Retighten

–

Insufficient tire pressure

Inflate

G-73

Steering controller malfunctioning

Replace

Relief valve malfunctioning

Replace

7-S4

Steering Force
Fluctuates

Air sucked in pump due to leaking or missing of

oil

Fill

–

Air sucked in pump from suction circuit

Repair

–

Excessive Steering
Wheel Play

Steering linkage worn

Replace

Front Wheels Wander
to Right or Left

Air sucked in pump due to leak of oil

Fill

–

Air sucked in pump from suction circuit

Repair

–

Tire pressure uneven

Inflate

G-73

Insufficient bleeding

Bleed

Improper toe-in adjustment

Adjust

6-S5

Clearance between front axle center pivots and

brackets bushings excessive

Replace

6-S19

Tie-rod end loose or worn

Retighten or replace

7-S7

Steering linkage worn

Replace

Steering controller malfunctioning

Replace

Wheels Are Turned to
a Direction Opposite
to Steering Direction

Power steering hoses connected in reverse

Repair
