STEERING

L3560, L4060, L4760, L5060, L5460, L6060, WSM

7-S2

2. SERVICING SPECIFICATIONS

STEERING CONTROLLER

STEERING CYLINDER

9Y1210824STS0002US0

Item

Factory Specification

Allowable Limit

Relief Valve

Condition

• Engine Speed

Maximum

• Oil Temperature

40 to 60 °C (104 to 140 °F)

Setting Pressure

L3560, L4060

L4760, L5060,

L5460, L6060

10.7 to 11.7 MPa

110 to 119 kgf/cm

2

1560 to 1690 psi

12.7 to 13.7 MPa

130 to 139 kgf/cm

2

1850 to 1980 psi

–

–

Item

Factory Specification

Allowable Limit

Steering Cylinder

I.D.

55.000 to 55.074 mm

2.1654 to 2.1682 in.

55.100 mm

2.1693 in.

Rod to Bushing

Clearance

0.00900 to 0.127 mm

0.000355 to 0.00500 in.

0.135 mm

0.00531 in.

KiSC issued 03, 2016 A
