STEERING

L3560, L4060, L4760, L5060, L5460, L6060, WSM

7-S3

3. TIGHTENING TORQUES

Tightening torques of screws, bolts and nuts on the table below are especially specified.

(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)

9Y1210824STS0003US0

Item

N·m

kgf·m

lbf·ft

Power steering hose retaining nut

25 to 29

2.5 to 3.0

18 to 21

Power steering delivery pipe retaining nut

49 to 58

5.0 to 6.0

37 to 43

Front wheel mounting nut

137

14.0

101

Tie-rod end slotted nut (L3560, L4060)

40 to 45

4.0 to 4.6

29 to 33

Tie-rod end slotted nut (L4760, L5060, L5460, L6060)

157 to 176

16.0 to 18.0

116 to 130

Tie-rod joint

167 to 196

17.0 to 20.0

123 to 144

Tie-rod joint lock nut

167 to 196

17.0 to 20.0

123 to 144

Steering wheel mounting nut

48.1 to 55.9

4.9 to 5.7

35.4 to 41.2
