Factory Specification; Allowable Limit- Page 556

HYDRAULIC SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

8-S3

Hydraulic Pump for Three Point Hitch

Condition

• Engine Speed

Approx. 2700 min

-1

 (rpm)

(Manual Transmission and GST)

Approx. 2600 min

-1

 (rpm)

(HST)

• Rated pressure

L3560

17.1 to 18.1 MPa

(175 to 184 kgf/cm

2

, 2480 to 2620 psi)

L4060, L4760, L5060, L5460, L6060

18.1 to 19.1 MPa

(185 to 194 kgf/cm

2

, 2630 to 2770 psi)

• Oil Temperature

40 to 60 °C (104 to 140 °F)

Delivery at No

Pressure

Manual

Transmission and

GST

L3560

except L3560

HST

L3560

except L3560

Above

31.5 L/min.

8.32 U.S.gals/min.

6.93 Imp.gals/min.

Above

37.0 L/min.

9.77 U.S.gals/min.

8.14 Imp.gals/min.

Above

30.4 L/min.

8.03 U.S.gals/min.

6.69 Imp.gals/min.

Above

35.6 L/min.

9.40 U.S.gals/min.

7.83 Imp.gals/min.

–

–

–

–

Delivery at Rated

Pressure

Manual

Transmission and

GST

L3560

except L3560

HST

L3560

except L3560

Above

30.9 L/min.

8.16 U.S.gals/min.

6.80 Imp.gals/min.

Above

36.3 L/min.

9.59 U.S.gals/min.

7.98 Imp.gals/min.

Above

29.7 L/min.

7.87 U.S.gals/min.

6.56 Imp.gals/min.

Above

34.9 L/min.

9.22 U.S.gals/min.

7.68 Imp.gals/min.

27.6 L/min.

7.29 U.S.gals/min.

6.07 Imp.gals/min.

32.4 L/min.

8.56 U.S.gals/min.

7.13 Imp.gals/min.

26.6 L/min.

7.03 U.S.gals/min.

5.85 Imp.gals/min.

31.2 L/min.

8.24 U.S.gals/min.

6.86 Imp.gals/min.

Bushing to Gear Shaft

• Gear Shaft

• Bushing

Clearance

O.D.

I.D.

0.020 to 0.081 mm

0.0079 to 0.0031 in.

14.970 to 14.980 mm

0.58937 to 0.57976 in.

15.000 to 15.051 mm

0.59056 to 0.59256 in.

0.15 mm

0.0059 in.

–

–

Side Plate

Thickness

2.48 to 2.50 mm

0.0977 to 0.0984 in.

2.40 mm

0.0945 in.

Item

Factory Specification

Allowable Limit

KiSC issued 03, 2016 A
