L3560, L4060, L4760, L5060, L5460, L6060, WSM

8-S5

3. TIGHTENING TORQUES

Tightening torques of screws, bolts and nuts on the table below are especially specified.

(For general use screws, bolts and nuts: Refer to "5. TIGHTENING TORQUES" on page G-11.)

9Y1210824HYS0003US0

Item

N·m

kgf·m

lbf·ft

Regulator delivery pipe joint bolt

40 to 49

4.0 to 5.0

29 to 36

Main delivery pipe joint bolt

49 to 54

5.0 to 5.6

37 to 40

Relief valve assembly

35 to 39

3.5 to 4.0

26 to 28

Safety valve assembly

40 to 49

4.0 to 5.0

29 to 36

Safety valve lock nut

59 to 78

6.0 to 8.0

44 to 57

Power steering delivery pipe joint bolt

40 to 49

4.0 to 5.0

29 to 36

PTO delivery pipe joint bolt

35 to 39

3.5 to 4.0

26 to 28

Regulating valve mounting screw

18 to 20

1.8 to 2.1

13 to 15

Hydraulic pump assembly mounting screw and nut

24 to 27

2.4 to 2.8

18 to 20

Pump cover mounting screw

40 to 44

4.0 to 4.5

29 to 32

Hydraulic cylinder hose retaining nut

35 to 48

3.5 to 4.9

26 to 35

Delivery pipe joint bolt

49 to 68

5.0 to 7.0

37 to 50

Unload plug

40 to 58

4.0 to 6.0

29 to 43

Plug 2

40 to 58

4.0 to 6.0

29 to 43

Plug 1

40 to 58

4.0 to 6.0

29 to 43

Lift arm pin mounting nut

78 to 90

7.9 to 9.2

58 to 66

Lift arm pin lock nut

63 to 72

6.4 to 7.4

47 to 53

Drawbar frame mounting screw (M14)

167 to 196

17.0 to 20.0

123 to 144

Drawbar frame mounting screw (M12)

78 to 90

7.9 to 9.2

58 to 66

Top link holder mounting screw

78 to 90

7.9 to 9.2

58 to 66

Joint bolt for delivery pipe 1 and 2

118 to 137

12.0 to 14.0

46.8 to 101
