L3560, L4060, L4760, L5060, L5460, L6060, WSM

8-S10

(Continued)

Manual Transmission and GST [L3560]

Manual Transmission and GST [except L3560]

HST [L3560]

HST [except L3560]

9Y1210824HYS0007US0

Hydraulic pump delivery

at no pressure

Factory specification

Above

31.5 L/min.

8.32 U.S.gals/min.

6.93 Imp.gals/min.

Hydraulic pump delivery

at rated pressure

Factory specification

Above

30.9 L/min.

8.16 U.S.gals/min.

6.80 Imp.gals/min.

Allowable limit

27.6 L/min.

7.29 U.S.gals/min.

6.07 Imp.gals/min.

Hydraulic pump delivery

at no pressure

Factory specification

Above

37.0 L/min.

9.77 U.S.gals/min.

8.14 Imp.gals/min.

Hydraulic pump delivery

at rated pressure

Factory specification

Above

36.3 L/min.

9.59 U.S.gals/min.

7.98 Imp.gals/min.

Allowable limit

32.4 L/min.

8.56 U.S.gals/min.

7.13 Imp.gals/min.

Hydraulic pump delivery

at no pressure

Factory specification

Above

30.4 L/min.

8.03 U.S.gals/min.

6.69 Imp.gals/min.

Hydraulic pump delivery

at rated pressure

Factory specification

Above

29.7 L/min.

7.87 U.S.gals/min.

6.56 Imp.gals/min.

Allowable limit

26.6 L/min.

7.03 U.S.gals/min.

5.85 Imp.gals/min.

Hydraulic pump delivery

at no pressure

Factory specification

Above

35.6 L/min.

9.40 U.S.gals/min.

7.83 Imp.gals/min.

Hydraulic pump delivery

at rated pressure

Factory specification

Above

34.9 L/min.

9.22 U.S.gals/min.

7.68 Imp.gals/min.

Allowable limit

31.2 L/min.

8.24 U.S.gals/min.

6.86 Imp.gals/min.

KiSC issued 03, 2016 A
