L3560, L4060, L4760, L5060, L5460, L6060, WSM

8-S17

[2] THREE POINT HITCH HYDRAULIC BLOCK ASSEMBLY

(1) Separating Hydraulic Block Assembly

Seat and Seat Bracket

1. Disconnect the seat switch connector (1) and seat tilt switch

connector (2).

2. Remove the seat (3).

3. Remove the seat suspension (4) together with seat bracket (5).

9Y1210824HYS0018US0

(1) Seat Switch Connector

(2) Seat Tilt Switch Connector

(3) Seat

(4) Seat Suspension

(5) Seat Bracket

KiSC issued 03, 2016 A
