L3560, L4060, L4760, L5060, L5460, L6060, WSM

8-S25

Seat and Seat Bracket

1. Disconnect the seat switch connector (1) and seat tilt switch

connector (2).

2. Remove the seat (3).

3. Remove the seat suspension (4) together with seat bracket (5).

9Y1210824HYS0018US0

Rear Wheel

1. Place the disassembling stand under the transmission case.

2. Remove the rear wheel mounting screws and nuts.

3. Remove the rear wheel R.H. (1).

9Y1210824HYS0031US0

(1) Seat Switch Connector

(2) Seat Tilt Switch Connector

(3) Seat

(4) Seat Suspension

(5) Seat Bracket

(1) Rear Wheel R.H.

KiSC issued 03, 2016 A
