ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-M40

(Error Messages)
Manual Transmission

GST

Display on IntelliPanel™

Trouble Item (Affected Model)

ERROR No. 20

CAN NG

Communication error between

ECU and IntelliPanel™

ERROR No. 30

ECU Memory DEVICE NG

ECU's memory device is in

trouble

ERROR No. 40

Input Voltage NG

Input voltage to sensor from

ECU is in trouble

ERROR No. 51

Shuttle SWITCH NG

Shuttle lever switch is in trouble

ERROR No. 93

Starter RELAY NG

Starter relay is in trouble

ERROR No. 94

OPC NG

OPC is in trouble

ERROR No. 95

PTO SOLENOID NG

Solenoid (PTO) is in trouble

Display on IntelliPanel™

Trouble Item (Affected Model)

ERROR No. 20

CAN NG

Communication error between

ECU and IntelliPanel™

ERROR No. 30

ECU Memory DEVICE NG

ECU's memory device is in

trouble

ERROR No. 40

Input Voltage NG

Input voltage to sensor from

ECU is in trouble

ERROR No. 50

GST Lever SENSOR NG

GST lever sensor is in trouble

ERROR No. 51

Shuttle SWITCH NG

Shuttle lever switch is in trouble

ERROR No. 60

GST SOLENOID NG

Proportional reducing valve is in

trouble

ERROR No. 61

1, 7, 8th Speed NG

Solenoid 1 is in trouble

(At forward or neutral)

ERROR No. 61

1, 5th Speed NG

Solenoid 1 is in trouble

(At reverse)

ERROR No. 61

1st Speed NG

Solenoid 1 is in trouble

ERROR No. 62

2, 9, 10th Speed NG

Solenoid 2 is in trouble

(At forward or neutral)

ERROR No. 62

2, 6th Speed NG

Solenoid 2 is in trouble

(At reverse)

ERROR No. 62

2nd Speed NG

Solenoid 2 is in trouble

ERROR No. 63

3, 4, 11th Speed NG

Solenoid 3 is in trouble

(At forward or neutral)

ERROR No. 63

3, 7th Speed NG

Solenoid 3 is in trouble

(At reverse)

ERROR No. 63

3rd Speed NG

Solenoid 3 is in trouble

ERROR No. 64

5, 6, 12th Speed NG

Solenoid 4 is in trouble

(At forward or neutral)

ERROR No. 64

4, 8th Speed NG

Solenoid 4 is in trouble

(At reverse)

ERROR No. 64

4th Speed NG

Solenoid 4 is in trouble

ERROR No. 65

1-6th Speed NG

Solenoid 5 (Hi-Lo) is in trouble

(At forward or neutral)

KiSC issued 03, 2016 A
