L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-M48

[5] ENGINE STARTING CONDITIONS

When the following conditions become complete,

electric voltage reaches starter

terminal through

operator presence controller from main switch

terminal, and the engine can be started.

9Y1210824ELM0079US0

(1) Shuttle Shift Lever

(2) PTO Switch

(3) Seat Switch

(4) Seat Tilt Switch

(5) HST Pedal

[A] Manual Transmission and

GST

[B] HST

PTO Switch

(Neutral: OFF)

(Engaged: ON)

Shuttle Switch

(Neutral: OFF)

(Engaged: ON)

HST Pedal Sensor

(Neutral: OFF)

(Engaged: ON)

Manual Transmission and GST

OFF

–

HST

OFF

–

OFF

KiSC issued 03, 2016 A
