1. TROUBLESHOOTING; Probable Cause; Reference - Page 639

Kubota L3560 Owners Manual

2014 Dodge Charger SRT Owner Manual

Table of Contents

L3560,L4060,L4760,L5060,L5460,L6060
9 ELECTRICAL SYSTEM
background image

ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S1

1. TROUBLESHOOTING

BATTERY

STARTING SYSTEM

OPC SYSTEM

Symptom

Probable Cause

Solution

Reference

Page

All Electrical
Equipment Do Not
Operate

Battery discharged or damaged

Recharge or replace

9-S12

Battery positive cable disconnected or improperly

connected

Repair or replace

Battery negative cable disconnected or

improperly connected

Repair or replace

Slow blow fuse blown

Replace

9-S34

Fuse Blown
Frequently

Short-circuited

Repair or replace

Symptom

Probable Cause

Solution

Reference

Page

Battery Discharges
Too Quickly

Battery damaged

Replace

9-S11

Alternator damaged

Repair or replace

9-S91

IC Regulator damaged

Replace

9-S92

Wiring harness disconnected or improperly

connected

Repair or replace

Cooling fan belt slipping

Adjust tension

G-28

Symptom

Probable Cause

Solution

Reference

Page

Starter Motor Does
Not Operate

Battery discharged or damaged

Recharge or replace

9-S12

Slow blow fuse blown

Replace

9-S34

Safety switch improperly adjusted or damaged

Repair or replace

9-S62

Wiring harness disconnected or improperly

connected

Repair or replace

Starter motor damaged

Repair or replace

9-S91

Main switch damaged

Replace

9-S60,

9-S61

Starter relay damaged

Replace

9-S66

PTO switch damaged

Replace

9-S62

Glow Lamp Does Not
Light

Coolant temperature sensor damaged

Replace

9-S74

Main switch damaged

Replace

9-S60,

9-S61

Glow relay damaged

Repair or replace

Electronic instrument panel damaged

Replace

9-S15

Symptom

Probable Cause

Solution

Reference

Page

Does Not Stop
Engine

OPC system electrical part damaged

Inspect or replace

safety switch
