ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S2

CHARGING SYSTEM

LIGHTING SYSTEM

EASY CHECKER™

Symptom

Probable Cause

Solution

Reference

Page

Charging Lamp Does
Not Light when Main
Switch is Turned ON

Wiring harness disconnected or improperly

connected

Repair or replace

–

Alternator damaged

Repair or replace

9-S91

Charging Lamp Does
Not Go Off When
Engine is Running

Short circuit between alternator terminal

L

 lead

and chassis

Repair or replace

–

Alternator damaged

Repair or replace

9-S91

Symptom

Probable Cause

Solution

Reference

Page

Head Light Does Not
Light

Fuse blown

Replace

9-S33

Bulb blown

Replace

G-46

Wiring harness disconnected or improperly

connected

Repair or replace

–

Hazard Light Does
Not Light

Fuse blown

Replace

9-S33

Bulb blown

Replace

G-46

Wiring harness disconnected or improperly

connected

Repair or replace

–

Flasher unit damaged

Replace

9-S71

Hazard switch damaged

Replace

9-S70

Symptom

Probable Cause

Solution

Reference

Page

Engine Oil Pressure
Lamp Lights Up
When Engine Is
Running

Engine oil pressure too low

Repair engine

1-S14

Engine oil insufficient

Fill

G-9

Engine oil pressure switch damaged

Replace

9-S72

Short circuit between engine oil pressure switch

lead and chassis

Repair

9-S72

Electrical instrument panel damaged

Replace

9-S15

Engine Oil Pressure
Lamp Does Not Light
When Main Switch Is
Turned ON and
Engine Is Not
Running

Engine oil pressure switch damaged

Replace

9-S72

Wiring harness disconnected or improperly

connected

Repair or replace

–

Electrical instrument panel damaged

Replace

9-S15

KiSC issued 03, 2016 A
