ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S4

Error Display for Manual Transmission

Display on IntelliPanel

Trouble Item

Probable Cause

Solution

Reference

Page

ERROR No. 20

CAN NG

Communication error

between ECU and

IntelliPanel™

• CANbus wiring is disconnected

or short-circuited

• No signals from main ECU for

longer than 5 seconds (error

cleared if signal sent and

received later)

• Main ECU damaged

Check the communication line

Check the main ECU

connector

9-S38

ERROR No. 30

ECU Memory DEVICE NG

ECU's memory device is

in trouble

• Main ECU memory device

failure

Replace the main ECU

9-S14

ERROR No. 40

Input Voltage NG

Input voltage to sensor

from ECU is in trouble

• Power source (5 V) from

terminal

A8

 of main ECU is

dropped below 2.6 V for 0.1

second or more

• Wiring for sensor is

short-circuited

Check the output voltage at

main ECU connector

9-S39

Check the sensor connector

9-S48

Check the ground cable

9-S35

ERROR No. 51

Shuttle SWITCH NG

Shuttle lever switch is in

trouble

• Shuttle switch failure

Check the shuttle switch

9-S63

Replace the shuttle switch

9-S63

ERROR No. 93

Starter RELAY NG

Starter relay is in trouble

• Starter relay failure

• Wiring for starter relay is

disconnected or short-circuited

Engine does not start

Replace the starter relay

9-S66

Check the wiring connector of

starter relay

ERROR No. 94

OPC NG

OPC is in trouble

• Wiring for OPC is disconnected

or short-circuited

Engine is stopped

Check the wiring connector of

OPC

9-S62

Check the communication line

between terminal B18 of main

ECU and terminal 20 of

engine ECU

ERROR No. 95

PTO SOLENOID NG

Solenoid (PTO) is in

trouble

• PTO solenoid valve failure

• Wiring for PTO solenoid valve

is disconnected or

short-circuited

• Grounding plate of solenoid is

poor contact with chassis

PTO does not rotate

Check the PTO solenoid valve

3-S20

Replace the PTO solenoid

valve

3-S66

Check the wiring connector of

PTO solenoid valve
