Trouble Item; Probable Cause; Reference - Page 645

ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S7

Error Display for HST

Display on IntelliPanel

Trouble Item

Probable Cause

Solution

Reference

Page

ERROR No. 20

CAN NG

Communication error

between ECU and

IntelliPanel™

• CANbus wiring is disconnected

or short-circuited

• No signals from main ECU for

longer than 5 seconds (error

cleared if signal sent and

received later)

• Main ECU damaged

Check the communication line

–

Check the main ECU

connector

9-S38

ERROR No. 30

ECU Memory DEVICE NG

ECU's memory device is

in trouble

• Main ECU memory device

failure

Replace the main ECU

9-S14

ERROR No. 40

Input Voltage NG

Input voltage to sensor

from ECU is in trouble

• Power source (5 V) from

terminal

A8

 of main ECU is

dropped below 2.6 V for 0.1

second or more

• Wiring for sensor is

short-circuited

Check the output voltage at

main ECU connector

9-S43

Check the sensor connector

9-S53

Check the ground cable

9-S35

ERROR No. 80

Range Shift SENSOR NG

Sensor for range gear

shift lever is in trouble

• Sensor output terminal is out of

adjustment

• Wiring for sensor is

disconnected or short-circuited

• Sensor failure

Check the sensor voltage by

test mode (Mode A)

9-S17

Check the sensor wiring

connector or check the sensor

resistance

9-S54

Replace the sensor

9-S54

ERROR No. 81

HST Pedal SENSOR NG

Sensor for speed control

pedal is in trouble

• Sensor output terminal is out of

adjustment

• Wiring for sensor is

disconnected or short-circuited

• Sensor failure

• Main sensor voltage ≤0.2 V or

≥4.9 V

• Sub sensor voltage ≤0.2 V or

≥4.9 V

• Main + Sub ≤3.9 V or ≥6.1 V (60

msec in a row)

The running that uses the

pedal is impossible, but

running with the cruise control

switch is possible

–

Check the sensor voltage by

Test mode (Mode A)

9-S17

Check the sensor wiring

connector or check the sensor

resistance

9-S55

Replace the sensor

9-S55

ERROR No. 82

Swash Plate SENSOR NG

Sensor for swashplate of

HST is in trouble

Travel motion is possible

–

Check the sensor voltage by

Test mode (Mode A)

9-S17

Check the sensor wiring

connector or check the sensor

resistance

9-S55

Replace the sensor

9-S55

ERROR No. 83

Cruise SWITCH NG

Cruise control switch is in

trouble

• Cruise control switch failure

Check the cruise control

switch

9-S57

Replace the cruise control

switch

9-S57

ERROR No. 84

Throttle SENSOR NG

Sensor for engine throttle

is in trouble

• Sensor output terminal is out of

adjustment

• Wiring for sensor is

disconnected or short-circuited

• Sensor failure

• Main sensor voltage ≤0.2 V or

≥4.9 V

• Sub sensor voltage ≤0.2 V or

≥4.9 V

• Main + Sub ≤3.9 V or ≥6.1 V (60

msec in a row)

Travel motion is possible. The

HST electronic control

function (Mode 2 and Mode 3)

is inoperative condition.

–

Check the sensor voltage by

Test mode (Mode A)

9-S17

Check the sensor wiring

connector or check the

sensorresistance

9-S55

Replace the sensor

9-S55
