2. SERVICING SPECIFICATIONS; Factory Specification; Allowable Limit- Page 647

ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S9

2. SERVICING SPECIFICATIONS

9Y1210824ELS0164US0

Item

Factory Specification

Allowable Limit

GST Proportional Reducing Valve

Resistance

Approx.

8 to 9 Ω

–

Shift Solenoid Valve

Resistance

Approx.

11 to 15 Ω

–

Glow Plug

Resistance

Approx.

0.8 Ω

–

Fuel Level Sensor

• Float at Upper-most Position

• Float at Lower-most Position

Resistance

Resistance

3.0 to 5.0 Ω

107.5 to 112.5 Ω

–

–

Coolant Temperature Sensor

• at −20 °C (−4 °F)

• at 20 °C (68 °F)

• at 80 °C (176 °F)

• at 100 °C (212 °F)

• at 120 °C (248 °F)

Resistance

Resistance

Resistance

Resistance

Resistance

13.54 to 16.63 kΩ

2.28 to 2.63 kΩ

0.30 to 0.33 kΩ

0.1836 kΩ

0.1108 kΩ

–

–

–

–

–

Starter

• Commutator

• Mica

• Brush

• Brush Holder and Holder Support

O.D.

Under Cut

Length

Resistance

30.0 mm

1.18 in.

0.50 to 0.80 mm

0.020 to 0.031 in.

15.0 mm

0.591 in.

Infinity

29.0 mm

1.14 in.

0.20 mm

0.0079 in.

11.0 mm

0.433 in.

–

Alternator

• Stator

• Rotor

• Slip Ring

• Brush

No-load voltage

Resistance

Resistance

O.D.

Length

More than

14 V

Less than

1.0 Ω

2.9 Ω

14.4 mm

0.567 in.

10.5 mm

0.413 in.

–

–

–

12.8 mm

0.504 in.

8.4 mm

0.331 in.
