Terminal Name; Connector B (34P Connector) of Wire Harness Side; Color of wiring- Page 678

ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S40

Connector B (34P Connector) of Wire Harness Side

9Y1210824ELS0035US0

No.

Color of wiring

Terminal Name

1

–

–

2

–

–

3

Y/B

Parked Regeneration Switch Lamp

4

W/L

Foot Throttle Sensor 1

5

–

–

6

–

–

7

Or

Traveling Speed Sensor

8

–

–

9

W/B

Seat Switch

10

L/G

Output Terminal for OPC

11

W/R

Foot Throttle Sensor 2

12

L/W

Auto Regeneration Switch Lamp

13

–

–

14

Y/L

Hand Throttle Sensor 1

15

Y/R

Hand Throttle Sensor 2

16

G/W

Mid PTO Switch

17

R/B

Seat Tilt Switch

18

–

–

19

–

–

20

–

–

21

–

–

22

–

–

23

Lg/B

Shuttle Switch (Forward)

24

Y/G

Shuttle Switch (Reverse)

25

–

–

26

–

–

27

–

–

28

L/Y

Parked Regeneration Switch

29

L/R

Auto Regeneration Switch

30

R

Starter

S

 Terminal

31

B/Y

Shuttle Switch (Neutral)

32

–

–

33

–

–

34

Or/B

PTO Switch
