Terminal Name; Connector B (34P Connector) of Wire Harness Side; Color of wiring- Page 682

ELECTRICAL SYSTEM

L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S44

Connector B (34P Connector) of Wire Harness Side

9Y1210824ELS0037US0

No.

Color of wiring

Terminal Name

1

–

–

2

Br/W

Swashplate Position Sensor 2

3

Y/B

Parked Regeneration Switch Lamp

4

W/L

HST Pedal Sensor 1

5

–

–

6

Y

Range Gear Shift Sensor

7

Or

Traveling Speed Sensor

8

–

–

9

W/B

Seat Switch

10

L/G

Output Terminal for OPC

11

W/R

HST Pedal Sensor 2

12

L/W

Auto Regeneration Switch Lamp

13

Br

Swashplate Position Sensor 1

14

Y/L

Hand Throttle Sensor 1

15

Y/R

Hand Throttle Sensor 2

16

G/W

Mid PTO Switch

17

R/B

Seat Tilt Switch

18

–

–

19

G/R

Cruise Control Switch (SET)

20

G/B

Cruise Control Switch (Increase)

21

W/G

Cruise Control Switch (Decrease)

22

W

Cruise Control Switch (Cancel)

23

G

Hi-Lo Switch (Hi)

24

L

Hi-Lo Switch (Lo)

25

–

–

26

–

–

27

B/Y

Throttle-Up Switch

28

L/Y

Parked Regeneration Switch

29

L/R

Auto Regeneration Switch

30

R

Starter

S

 Terminal

31

G/L

Auto Throttle Advance Switch

32

–

–

33

W/L

Cruise Control Release Switch

34

Or/B

PTO Switch

KiSC issued 03, 2016 A
