L3560, L4060, L4760, L5060, L5460, L6060, WSM

9-S90

(2) CCV Heater

Heater Resistance (for Reference)

1. Check the resistance between terminal

and

2. If the reference value is not indicated, the heater is faulty.

9Y1210824ELS0167US0

Resistance

at 25 °C (77 °F)

1.8 - 2.5 Ω

(1) CCV Heater (OUT)

(2) CCV Heater (IN)

(3) Connector of Switch Side

[A] Left Side
[B] Right Side

KiSC issued 03, 2016 A
