CABIN

L3560, L4060, L4760, L5060, L5460, L6060, WSM

10-S5

2. SERVICING SPECIFICATIONS

9Y1210824CAS0002US0

Item

Factory Specification

Allowable Limit

Refrigerating Cycle

(Refrigerating Cycle is Normal Operating)

Pressure

(

LO

 Pressure Side)

Pressure

(

HI

 Pressure Side)

0.15 to 0.20 MPa

1.5 to 2.0 kgf/cm

2

21 to 28 psi

1.27 to 1.66 MPa

13 to 17 kgf/cm

2

185 to 242 psi

–

–

Pressure Switch (Dual Type)

(When pressure switch is turned

OFF

)

Setting Pressure

(

LO

 Pressure Side)

Setting Pressure

(

HI

 Pressure Side)

Less than

approx.

0.196 MPa

2.00 kgf/cm

2

28.4 psi

More than

approx.

2.94 MPa

30.0 kgf/cm

2

426 psi

–

–

Air-gap of A/C Compressor Magnet Clutch

Air-gap

0.20 to 0.45 mm

0.0079 to 0.017 in.

–

Air Conditioner Drive Belt

Tension

10 to 12 mm

(0.39 to 0.47 in.)

deflection at 98 N

(10 kgf, 22 lbf) of force

–

KiSC issued 03, 2016 A
