GENERAL

L3560, L4060, L4760, L5060, L5460, L6060, WSM

G-49

Replacing Oil Cooler Line [HST Type]

1. Replace if any deterioration (crack, hardening, scar of

deformation) or damage occurred.

Refer to "Checking HST Oil Line and Power Steering Line".

(See page G-37.)

9Y1210824GEG0141US0

Replacing Oil Separator Hose

1. Replace if any deterioration (crack, hardening, scar of

deformation) or damage occurred. (See page 1-S17.)

9Y1210824GEG0142US0

KiSC issued 03, 2016 A
