Removing a Second Row Outer Seat- Page 229

uu

Seats

u

Second Row Seats

228

Co
ntrols

Your vehicle’s second row outer seats are removable.

1.

Lower the head restraint to its lowest
position.

2.

Move the seat to its rearmost position.

3.

Pull the seat-back angle adjustment lever,
then fold the seat-back down.

4.

Pull the lock release lever, tilt the seat-back
forward and lift the rear of the seat.

u

To lift the seat, grab the handle under
the rear side of the seat.

5.

Pivot the rear of the seat upward to unhook
the front of the seat from the floor.

■

Removing a Second Row Outer Seat

1

Removing a Second Row Outer Seat

Do not remove the seat while driving.

Reinstalling a Second Row Outer Seat

With the seat-back folded forward, insert the front
seat hooks into the front floor strikers.

After confirming both front hooks are fully inserted
into the front strikers, begin to lower the seat, then
allow it to drop and lock to the rear floor strikers.

Raise the seat-back to an upright position, then rock
the seat-back and forth to confirm both the inner and
outer latches are securely locked into position.

Handle

Seat-back Angle
Adjustment Lever

Lock Release Lever
