Restraint Positions; To raise the head restraint:; To lower the head restraint:- Page 238

237

uu

Seats

u

Head Restraints

Co
ntrols

A passenger sitting in the second row/third
row center seating position should adjust the
height of their head restraint to an
appropriate position before the vehicle begins
moving.

To raise the head restraint:

Pull it upward.

To lower the head restraint:

Push it down while pressing the release
button.

Head restraints can be removed for cleaning or repair.

To remove a head restraint:

Pull the restraint up as far as it will go. Then, push the release button and pull the
restraint up and out.

To reinstall a head restraint:

Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Changing the Second Row

*

/Third Row Center Seat Head

Restraint Positions

■

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

To remove the third row seat outer head restraints,
fold down the seat-back first.

2

Third Row Seats

 P. 230

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

* Not available on all models
