Using Automatic Climate Control; Switching between the recirculation and fresh air modes- Page 261

260

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.

1.

Press the

AUTO

 button.

2.

Adjust the interior temperature using the temperature control switch.

3.

Press the

 button to cancel.

■

Switching between the recirculation and fresh air modes

Press the

 button and switch the mode depending on environmental

conditions.
Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Dual-zone climate control system

1

Using Automatic Climate Control

During idle-stops, air-conditioning is suspended, and
only the blower remains active. If you do not want
air-conditioning suspended, press Auto Idle Stop

OFF

button to cancel idle-stop.

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The

AUTO

 indicator will go off, but functions

unrelated to the button that was pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the

AUTO

button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit,

Lo

 or

Hi

 is displayed.

Pressing the

 button switches the climate

control system between on and off. When turned on,
the system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

Dashboard
vents

Dashboard
and floor
vents

Floor vents

Floor and
defroster
vents

AUTO

 Button

Temperature
Control Switch

A/C

 (Air Conditioning) Button

Fan Control
Switch

(Recirculation)
Button

 (On/Off)

Button

SYNC

(Synchronized)
Button

 (Windshield Defroster) Button

MODE

 Button
