Programming a Button- Page 485

uu

HomeLink

®

 Universal Transceiver

*

u

Training HomeLink

484

Features

■

Programming a Button

1

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

2.

1.

Press and hold the desired HomeLink button until
the HomeLink indicator begins to

slowly flash

orange

. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from

orange to rapidly flashing green

.

This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simple press and release the
programmed HomeLink button. Activation will now
occur for the trained device.

Questions
For questions or comments, visit

www.HomeLink.com

,

www.youtube.com/

HomeLinkGentex

, or by calling the HomeLink Hotline

(North America only) at (800) 355-3515.

HomeLink

®

 is a registered trademark of Gentex

Corporation.

Training
Complete

HomeLink LED is

continuously on green

.

YES

YES

1.

Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the
HomeLink

®

 button you want to program.

3b.

Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from

slowly flashing orange to

rapidly flashing or continuously on
green

? The process should take less

than 60 seconds.

NO

2.

Press and release the desired HomeLink button. Is the HomeLink indicator (LED)

slowly

flashing orange

?

NO

3a.

Hold the button on the remote
transmitter. Does HomeLink indicator
(LED) change from

slowly flashing

orange to rapidly flashing green or
continuously on green

? The process

should take less than 60 seconds.

5.

Press and hold the HomeLink button again.

HomeLink indicator

rapidly flashes

green

.

5a.

The remote has a rolling code. Press the
“learn” button on the remote-controlled
device (e.g. garage door opener).

6.

Press and hold the HomeLink button
again.
The remote-controlled device should
operate.

Training Complete

5b.

Within 30 secs, press and hold the
programmed HomeLink button for 2
secs.

4.

Press and hold the programmed HomeLink
button for about a second. Does the device
(garage door opener) work?
