Airbags

u

Airbag System Components

Safe Driving

The front, driver’s knee, front passenger’s
knee, side, and side curtain airbags are
deployed according to the direction and
severity of impact. Both side curtain airbags
are deployed in a rollover. The airbag
system includes:

a

Two SRS (Supplemental Restraint System)
front airbags. The driver’s airbag is stored
in the center of the steering wheel; the
front passenger’s airbag is stored in the
dashboard. Both are marked

SRS

AIRBAG

.

b

Two knee airbags. The driver’s knee
airbag is stored under the steering
column; the front passenger’s knee
airbag is stored under the glove box.
Both are marked

SRS AIRBAG

.

c

Two side airbags, one for the driver and
one for the front passenger. The airbags
are stored in the outer edges of the seat-
backs. Both are marked

SIDE AIRBAG

.

d

Two side curtain airbags, one for each
side of the vehicle. The airbags are stored
in the ceiling, above the side windows.

The front and rear pillars are marked

SIDE CURTAIN AIRBAG

.

e

An electronic control unit that, when the
vehicle is on, continually monitors
information about the various impact
sensors, seat and buckle sensors, rollover
sensor, airbag activators, seat belt
tensioners, and other vehicle
information. During a crash event the
unit can record such information.

f

Automatic front seat belt tensioners. In
addition, the driver’s and front
passenger’s seat belt buckles incorporate
sensors that detect whether or not the
belts are fastened.

g

Driver’s seat position sensor. This sensor
detects the driver’s seat slide position to
help determine the optimal deployment
of the driver’s airbag.

h

Weight sensors in the front passenger’s
seat. The sensors are used for occupant
classification to activate or deactivate the
front passenger’s airbag.

i

Impact sensors that can detect a
moderate-to-severe front or side impact.

j

An indicator on the dashboard that alerts
you that the front passenger’s front
airbag has been turned off.

k

An indicator on the instrument panel that
alerts you to a possible problem with your
airbag system or seat belt tensioners.

l

Safing Sensor

m

A rollover sensor that can detect if your
vehicle is about to roll over and signal the
control unit to deploy both side curtain
airbags.
