Front Side Marker Light Bulbs; Passenger side: ; Driver side: - Page 689

688

uu

Replacing Light Bulbs

u

Front Side Marker Light Bulbs

Main

tenan

ce

Front Side Marker Light Bulbs

When replacing, use the following bulb.

1.

Turn the steering wheel all the way to the
opposite side from the light being replaced.

Passenger side:

Turn the steering wheel

to the left.

Driver side:

Turn the steering wheel to the

right.

2.

Remove the holding clip and screw, and
pull the inner fender back.

3.

Rotate the socket counter-clockwise and
remove it.

4.

Remove the old bulb and insert a new bulb.

Side Turn Signal/Emergency Indicator Lights

*

Door mirror side turn lights are LED type. Have an authorized Honda dealer inspect
and replace the light assembly.

Front Side Marker Light: 3 CP

1

Front Side Marker Light Bulbs

Press down the center pin until it clicks to unlock it.

Push the center pin back to lock the clip. Then, insert
the clip into the hole and press on the center pin until
it is flat.

Center pin

Push until
the pin is
flat.

Clip

Screw

Socket

Bulb

* Not available on all models
