Continued

695

uu

Checking and Maintaining Wiper Blades

u

Changing the Rear Wiper Blade Rubber

Main

tenan

ce

7.

Insert the flat side of the new wiper blade
onto the bottom part of the holder. Insert
the blade all the way.

8.

Install the end of the wiper blade into the
cap.

9.

Slide the holder onto the wiper arm until it
locks.

10.

Lower both wiper arms.

11.

Set the power mode to ON and hold the
wiper switch in the

MIST

 position until

both wiper arms return to the standard
position.

Changing the Rear Wiper Blade Rubber

1.

Raise the wiper arm off.

2.

Pivot the bottom end of the wiper blade up
until it comes off from the wiper arm.

Cap

Wiper
Blade

Holder

1

Changing the Rear Wiper Blade Rubber

NOTICE

Avoid dropping the wiper arm, it may damage the
rear window.

Wiper
Blade

Wiper
Arm
