Installing a LATCH-compatible child seat in the ; third row center seat- Page 75

uu

Child Safety

u

Safety of Infants and Small Children

74

Safe Driving

3.

Put the head restraint to its upper-most
position, then route the tether strap
outside/between the head restraint legs,
and secure the tether strap hook to the
anchor.

4.

Tighten the tether strap as instructed by the
child seat manufacturer.

1

Installing a LATCH-Compatible Child Seat

Installing a LATCH-compatible child seat in the
third row center seat

Each outer third row seat is equipped with a pair of
lower anchors which are used to secure a LATCH-
compatible child seat. The third row center seat,
however, is not equipped with anchors of any kind.
The inner and outer anchors are spaced apart at a
standard distance of 11 inches (280 mm). The
distance between the two inner anchors is 16.0
inches (406.2 mm).
LATCH-compatible restraint systems that are fitted
with rigid-type attachments cannot be installed in the
third row center seat. However, a system fitted with
flexible-type attachments can be installed in the third
row center seat, provided that the manufacturer’s
instructions for that system permit the use of the
inner anchors with the stated spacing.
Before seating a child, make sure that the system is
properly attached to both the lower anchors and
tether anchors.

Anchor

Tether Strap
Hook

Anchor

Tether Strap
Hook

Other Top Tether Type

Second row outer position
Straight Top Tether Type
