Add New; Start Import; Wallpaper Setup- Page 262

uu

Audio System Basic Operation

u

Audio/Information Screen

260

Features

You can change, store, and delete the wallpaper on the audio/information screen.

■

Import wallpaper

You can import up to five images, one at a time, for wallpaper from a USB flash
drive.

1.

Connect the USB flash drive to the USB
port.

2

USB Port(s)

 P. 227

2.

Select

Settings

.

3.

Select

Clock

.

4.

Select

Clock/Wallpaper Type

, then open

the

Wallpaper

 tab.

5.

Select

Add New

.

u

The picture name is displayed on the list.

6.

Select a desired picture.

u

The preview is displayed on the left side
on the screen.

7.

Select

Start Import

 to save the data.

u

The display will return to the wallpaper
list.

■

Wallpaper Setup

1

Wallpaper Setup

The wallpaper you set up on

Clock/Wallpaper Type

cannot be displayed on the driver information
interface.

•

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

•

The file name must be fewer than 64 characters.

•

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

•

The individual file size limit is 5 MB.

•

The maximum image size is 4,096 × 4,096 pixels. If
the image size is less than 800 × 480 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

•

If the USB flash drive does not have any pictures,
the

No files detected

 message appears.

After changing the screen interface design, you can
change the wallpaper by following procedure.
1. Press the

 button.

2. Select and hold empty space on the home screen.

The pop-up menu appears on the screen.

3. Select

Change wallpaper

.

4. Select

Gallery

,

Live wallpapers

, or

Wallpapers

.
