Fog Light Bulbs; Fog Light: 35 W (H8 for halogen bulb type)- Page 598

596

uu

Replacing Light Bulbs

u

Fog Light Bulbs

*

Main

tenan

ce

Fog Light Bulbs

*

When replacing, use the following bulbs.

1.

Remove the clips using a flat-tip
screwdriver, remove the bolt, and push up
the under cover.

Fog Light: 35 W (H8 for halogen bulb type)

1

Fog Light Bulbs

*

Insert a flat-tip screwdriver, lift and remove the center
pin to remove the clip.

Insert the clip with the center pin raised, and push
until it is flat.

Push until the pin
is flat.

Models with halogen fog lights

Clips

Bolt

* Not available on all models
