Checking and Maintaining Wiper Blades

u

Changing the Rear Wiper Blade Rubber

*

Continued

Main

tenan

ce

Changing the Rear Wiper Blade Rubber

*

1.

Raise the wiper arm off.

2.

Press up on and hold the tab, then slide the
holder off the wiper arm.

3.

Pull the end of the wiper blade in the
direction of the arrow in the image until it is
out of the holder’s end cap.

1

Changing the Rear Wiper Blade Rubber

*

NOTICE

Avoid dropping the wiper arm, it may damage the
rear window.

Tab

Wiper Arm

Holder

Wiper
Blade

End cap at
the bottom

* Not available on all models
