Jacking Points- Page 659

Continued

657

uu

Handling of the Jack

*

u

How to Set Up the Jack

Han

d

lin
g the U

n

expected

3.

Place a wheel block or rock in front and rear
of the wheel diagonal to the flat tire.

4.

Place the jack under the jacking point
closest to the tire to be changed.

5.

Turn the end bracket clockwise as shown in
the image until the top of the jack contacts
the jacking point.

u

Make sure that the jacking point tab is
resting in the jack notch.

1

How to Set Up the Jack

Do not use the jack with people or luggage in the
vehicle.

Use the jack provided in your vehicle.
Other jacks may not support the weight (“load”) or
may not fit the jacking point.

The following instructions must be followed to use
the jack safely:

•

Do not use while the engine is running.

•

Use only where the ground is firm and level.

•

Use only at the jacking points.

•

Do not get in the vehicle while using the jack.

•

Do not put anything on top of or underneath the
jack.

Jacking Points

Jacking Point
