Power Sliding Door Switches; Auto Reverse- Page 187

uu

Sliding Doors

u

Opening/Closing the Power Sliding Doors

*

186

Co
ntrols

The power sliding door opens when you press
the

OPEN

 side of the

 /

 switch, and

closes when you press the

CLOSE

 side of the

 /

 switch.

While the power sliding door is in operation, if
you press the switch that corresponds to that
power sliding door, the beeper sounds and
the operation stops.

To resume the power sliding door operation,
press the same switch again.

■

Power Sliding Door Switches

1

Opening/Closing the Power Sliding Doors

*

Auto Reverse

Do not touch the pinch sensor located at the front
edge of the power sliding door. Do not damage the
sensor. The power sliding door may not operate
properly.

If the power sliding door senses resistance when
closing automatically, it will stop closing and reverse
direction. The beeper sounds.

Before the power sliding door operation, make sure
there are no people or obstacles near the door. The
auto reverse function should be activated in case of
emergency only. If someone is caught in the opening
or closing sliding door, it can cause serious injury. Pay
special attention to children.

Closing a power sliding door on someone’s hand or
fingers can cause serious injury. Some parts of the
door edge do not sense resistance when the door is
near closing.

Pinch
Sensor

* Not available on all models
