33

SHIFT POSITION

INDICATOR

TACHOMETER

Instrument Cluster

ODOMETER/

TRIP METER

IMPORTANT:

When your

Mazda Connect display setting

is set on “AUTO”, the instrument

cluster and display may become

dimmer when the headlights are

on. If the display and instrument

cluster become too dim or too

bright when the headlights are on,

simply rotate the dimmer knob

located on your instrument cluster

to adjust the brightness.

GLOSSARY OF WARNING AND INDICATOR LIGHTS

Type A cluster is shown. Type B

cluster is similar, but with warning

lights in different locations.

*TPMS NOTE:

Low ambient temperature and/or high altitude causes tire pressures to drop

and may turn the TPMS warning light on. If the warning light comes on, check the tire pressure

and fill the tires as soon as possible, preferably before moving the vehicle and warming up

the tires. Initialize system (p. 6). Tire pressure should be checked when the tires are cold.

NOTE:

See Owner’s Manual for more details and explanations.

Low Engine Oil Pressure

Traction Control System (TCS)/

 Dynamic Stability Control (DSC)

On: TCS/DSC malfunction

 Flashing: TCS/DSC operating

  Shift Position Indicator


Power Steering Malfunction

Air Bag/Front Seat Belt

Pretensioner System Malfunction

Turn Signals/

 Hazard Warning Indicator


Check Engine

Master Warning

Tire Pressure Monitoring System

(TPMS) Warning*

 (p. 6)

On/Warning Beep: Low tire pressure in one
or more tires. Flashing: TPMS Malfunction

Security Indicator

Cruise Main Indicator

 ON (

AMBER

)/Cruise Set

 Indicator ON (

GREEN

)

Lights ON (Exterior)

(p. 25)

Seat Belt Unbuckled/Malfunction

Headlight High Beams On

Brake Warning

Parking brake on/low brake fluid/malfunction

  Charging System Malfunction

Antilock Brake System

 (ABS)  Malfunction

Low Fuel Level

  Smart City Brake Support

(SCBS) OFF Indicator

Smart Brake Support (SBS)

Warning Indication

  High Beam Control ON

(p. 28)

  Mazda Radar Cruise Control

Warning ON (

AMBER

)

Set Indicator (

GREEN

)

(pp. 17-18)

Headlight Warning

OFF

Dynamic Stability Control

(DSC) OFF
