Continued

537

uu

Honda Sensing

®

u

Lane Keeping Assist System (LKAS)

Driving

The system operation is suspended if
you:

Set the wipers to continuous operation.

u

Turning the wipers off or setting it to

LO



resumes the LKAS.

Set the wiper switch to

AUTO

 and the

wipers operate continuously.

u

The LKAS resumes when the wipers stop
or operate intermittently.

Decrease the vehicle speed to 40 mph (64
km/h) or less.

u

Increasing the vehicle speed to 45 mph
(72 km/h) or more resumes the LKAS.

Depress the brake pedal.

u

The LKAS resumes and starts detecting
the lane lines again once you release the
brake pedal.

The LKAS may automatically be suspended when:

The system fails to detect lane lines.

The steering wheel is quickly turned.

You fail to steer the vehicle.

Driving through a sharp curve.

Driving at a speed in excess of approximately 90 mph (145 km/h).

Once these conditions no longer exist, the LKAS automatically resumes.

1

The system operation is suspended if you:

You can change the setting for the LKAS.
LKAS suspended beep

ON

 and

OFF

 can be selected.

2

Customized Features

 P. 350

When the LKAS is suspended,
the lane lines on the driver
information interface change to
contour lines, and the beeper
sounds (if activated).

Models with automatic intermittent wipers

All models

21 CIVIC 5D HUM-31TGG6400_01.book  537 ページ  2020年8月28日 金曜日 午後1時48分
