Circuit protected and fuse rating- Page 677

675

uu

Fuses

u

Fuse Locations

Continued

Han

d

lin
g the U

n

expected

■

Circuit protected and fuse rating

Circuit Protected

Amps

1

Option Block 1

*

(60 A)

−

−

Cooling Fan

50 A

*4

30 A

*5

Audio AMP

*

(30 A)

IG Main 2

*1

(30 A)

Headlight High Beam Main

30 A

Battery

125 A

2

EPS

70 A

IG Main 1

30 A

*1

50 A

*2

Fuse Box Option

*

(40 A)

Fuse Box 1

60 A

Front Wiper Motor

30 A

Headlight Low Beam Main

30 A

3

Rear Defroster

40 A

Starter Motor

(30 A)

Fuse Box 2

40 A

ABS/VSA Motor

40 A

ABS/VSA FSR

40 A

Blower Motor

40 A

4

−

−

−

−

−

−

−

−

5

Cooling Fan

*4

(5 A)

6

Washer

15 A

7

FI Main

15 A

*4

20 A

*5

8

Stop Lights

10 A

9

FI Sub

15 A

10

Injector

*4

(15 A)

Sub Fan Motor

*5

20 A

11

LAF

5 A

12

FI ECU

10 A

13

Hazard

15 A

14

Rear Heated Seat

*

(15 A)

15

IG Coil

15 A

16

Transmission

*3

(15 A)

17

Daytime Running Lights

(10 A)

18

Back Up

10 A

19

Audio

(15 A)

20

Parking Lights

10 A

Circuit Protected

Amps

*1:Models with smart entry system
*2:Models without smart entry system
*3:Continuously variable transmission

models

*4:1.5 L engine models
*5:2.0 L engine models

21

Interior Lights

10 A

22

Front Fog Lights

*

(15 A)

23

A/C Compressor

10 A

24

Horn

10 A

25

−

−

26

Left Headlight Low Beam

10 A

27 Right Headlight Low Beam

10 A

28

−

−

29

Left Headlight High Beam

10 A

30 Right Headlight High Beam

10 A

31

Passenger’s Power Seat

Sliding

*

(20 A)

32

Passenger’s Power Seat

Reclining

*

(20 A)

Adaptive Damper System

*5

(15 A)

33

VB ACT

(5 A)

Circuit Protected

Amps

* Not available on all models
