Circuit protected and fuse rating

Circuit Protected

Amps

1

Accessory

10 A

2

Key Lock

(5 A)

3

Rear Wiper Motor

*

(10 A)

4

Front Sensor Camera

*1, *

Transmission

*2, *3

(5 A)

(10 A)

5

Option

(10 A)

6

SRS Indicator

(10 A)

7

Meter

10 A

8

Fuel Pump

15 A

*4

20 A

*5

9

AIRCON

10 A

10

−

−

11

Engine Control

*4

5 A

12 Passenger’s Side Door Lock

10 A

13

Driver’s Side Rear Door

Unlock

10 A

14

Rear Driver’s Side Power

Window

(20 A)

15

Front Passenger’s Side

Power Window

20 A

16

Door Lock

20 A

17

Transmission

*1, *3

Front Sensor Camera

*2, *

(10 A)

(5 A)

18

−

−

19

Moonroof

(20 A)

20

−

−

21

ACG

10 A

22

Daytime Running Lights

(10 A)

23

−

−

24

Front Sensor Camera

*

(5 A)

25

Driver’s Door Lock

(10 A)

26

Passenger’s Side Door

Unlock

10 A

27

Rear Passenger’s Side

Power Window

(20 A)

28

Driver’s Power Window

20 A

Circuit Protected

Amps

*1:Models with smart entry system
*2:Models without smart entry system
*3:Continuously variable transmission

models

*4:1.5 L engine models
*5:2.0 L engine models

29

Front Accessory Power

Socket

20 A

30

Smart Entry

*1

(10 A)

STS

*2

(5 A)

31

Driver’s Power Seat

Reclining

*

(20 A)

32

Front Seat Heater

*

(20 A)

33 Driver’s Power Seat Sliding

*

(20 A)

34

VSA/ABS

10 A

35

SRS

10 A

36

−

−

37

Option

(10 A)

38

Driver’s Side Rear Door

Lock

10 A

39

Driver’s Door Unlock

(10 A)

Circuit Protected

Amps

* Not available on all models
