Inspecting and Changing Fuses- Page 752

751

uu

Fuses

u

Inspecting and Changing Fuses

Han

d

lin
g the U

n

expected

Inspecting and Changing Fuses

1.

Set the power mode to VEHICLE OFF. Turn
headlights and all accessories off.

2.

Check the fuses on the battery in the
engine compartment.

u

If the fuse is blown, have it replaced by a
dealer.

3.

Remove the fuse box cover.

4.

Inspect the small fuses in the engine
compartment and the vehicle interior.

u

If there is a blown fuse, remove it with
the fuse puller and replace it with a new
one.

5.

Check the large fuse in the vehicle interior.

u

If the fuse is blown, use a Phillips-head
screwdriver to remove the screw and
replace it with a new one.

1

Inspecting and Changing Fuses

NOTICE

Replacing a fuse with one that has a higher rating
greatly increases the chances of damaging the
electrical system.

Use the charts to locate the fuse in question and
confirm the specified amperage on the fuse label.

2

Fuse Locations

 P. 745

Replace fuses with a spare fuse of the same specified
amperage.

There is a fuse puller on the back of the engine
compartment fuse box cover.

Blown

Fuse Box on the Battery

Fuse Puller

Combined Fuse

Blown Fuse
