Installing a LATCH-compatible child seat in the ; rear center seat- Page 72

uu

Child Safety

u

Safety of Infants and Small Children

70

Safe Driving

3.

Retract the cargo area cover.

2

Cargo Area Cover

*

 P. 213

4.

Route the tether strap over the top of the
head restraint and secure the tether strap
hook to the anchor.

5.

Tighten the tether strap as instructed by the
child seat manufacturer.

6.

Make sure the child seat is firmly secured by
rocking it forward and back and side to
side; little movement should be felt.

7.

Make sure any unused seat belt that a child
can reach is buckled, the lockable retractor
is activated, and the belt is fully retracted
and locked.

Flexible Type

Lower Anchors

1

Installing a LATCH-Compatible Child Seat

Installing a LATCH-compatible child seat in the
rear center seat

Each outer rear seat is equipped with a pair of lower
anchors which are used to secure a LATCH-
compatible child seat. The rear center seat, however,
is not equipped with anchors of any kind.
The inner and outer anchors are spaced apart at a
standard distance of 11 inches (280 mm). The
distance between the two inner anchors is 15 inches
(380 mm).
LATCH-compatible restraint systems that are fitted
with rigid-type attachments cannot be installed in the
rear center seat. However, a system fitted with
flexible-type attachments can be installed in the
center seat, provided that the manufacturer’s
instructions for that system permit the use of the
inner anchors with the stated spacing.

3

WARNING

Using the outer rear seats’ inner anchors to
secure a LATCH-compatible child seat in the
center seating position may result in failure
of the child seat, causing injury or death.

Only use the outer rear seats’ inner anchors
to install a child seat in the center seating
position if the manufacturer’s instructions
expressly permit.

Except 2.0 L engine models

Except 2.0 L engine models

Anchor

Straight Top Tether Type

Other Top Tether Type

Tether Strap Hook

Tether Strap Hook

Anchor

* Not available on all models
