How the System Works- Page 490

Continued

489

uu

Honda Sensing

®

u

Low Speed Braking Control

*

Driving

■

Assistive braking

Assistive braking provides a visual and audible alert when the vehicle is moving
between approximately 1 and 6 mph (2 and 10 km/h) and there is the possibility of
a collision with a detected wall or other obstacles, as well as providing assistance
with braking.

If the only rear sensors are turned off using the parking sensor system, the assistive
braking is not working when reversing.

2

Turning off All Rear Sensors

 P. 568

■

How the System Works

1

Low Speed Braking Control

*

For directions on the proper handling of the sonar
sensors, please refer to the following page.

2

Sonar Sensors

*

 P. 553

The vehicle will release the brake and start moving a
few seconds after the system is activated. To keep the
vehicle stopped, keep the brake pedal depressed or
put the transmission into

(

P

.

In order to prevent the system from activating when
not needed, always turn it off during vehicle
maintenance, when loading on ships, trucks, and so
on, or when using a chassis dynamometer, free
rollers for inspection or when washing the car in
conveyor type car wash machine.

Audible Alert

Beep

Beep

The vehicle
applies brake

Driver
depresses
brake pedal

Remove
brake after
maintaining
stationary
position

Stop

* Not available on all models
