Fuses

u

Fuse Locations

Han

d

lin
g the U

n

expected

■

Circuit protected and fuse rating

Circuit Protected

Amps

1

P/W DR

20 A

2

P/W AS

20 A

3

P/W RR R

20 A

4

P/W RR L

20 A

5

OPTION

10 A

6

SRS

10 A

7

T/G MTR / TRUNK ACT

10 A

8

-

-

9

FR ACC SOCKET

20 A

10

DOOR LOCK

20 A

11

METER

10 A

12

OPTION3 (ST CUT)

10 A

13

OPTION2 (RR WIP)

*

(10 A)

14

OPTION6 (VB SOL)

10 A

15

DR DOOR UNLOCK

(10 A)

16

SUNROOF

*

(20 A)

17

SBW1

*

(10 A)

18

-

-

19

-

-

20

RR FOG

*

(10 A)

21

CARGO ACC SOCKET

*

(20 A)

22

SMART

10 A

23

DR DOOR LOCK

(10 A)

24

SBW2

*

(7.5 A)

25


10 A

26

SRS

10 A

27

ACG / D/V / ST CUT RLY

20 A

28

OPTION5

10 A

29

FUEL PUMP

15 A

30

L SIDE DOOR UNLOCK

10 A

31

R SIDE DOOR UNLOCK

10 A

32

-

-

33

-

-

34

-

-

35

-

-

36

OPTION3 (SUNSHADE)

*

(20 A)

37

IGA2

*

(15 A)

38

-

-

39

R SIDE DOOR LOCK

10 A

40

P/SEAT REC / RR HI

*

(20 A)

41

P/SEAT SLIDE / FR HI

*

(20 A)

42

-

-

43

A/C

10 A

44

DRL

10 A

45

ACC

10 A

46

ACC KEY LOCK

10 A

47

L SIDE DOOR LOCK

 10 A

48

H/SEAT

20 A

49

AS P/SEAT REC

*

(20 A)

50

P/LUMBER DR

*

(10 A)

51

P/LUMBER AS

*

(10 A)

52

RR H/SEAT

*

(20 A)

Circuit Protected

Amps

53

AS P/SEAT SLI

*

(20 A)

54

OPTION1 / FUEL LID

10 A

55

AUDIO AMP

*

(30 A)

56

ADS

*

(30 A)

Circuit Protected

Amps

A

BACKUP2 MAIN

(10 A)

B

AUDIO SUB VST

*

(7.5 A)

C

ACC VST

(10 A)

D

VST 1

(10 A)

E

AUDIO VST

(15 A)

F

EOP

*

(20 A)

G

-

-

H

VST 2

(10 A)

Circuit Protected

Amps

Sub Fuse Box

* Not available on all models
