67

2-1. Instrument cluster

2

Vehi

cle

 status

inform

ati

on a

nd i

ndic
ators



Drive mode indicators



Except F SPORT models



F SPORT models

*1

: These lights come on when the engine

switch is turned to IGNITION ON
mode to indicate that a system check is
being performed. They will turn off after
the engine is started, or after a few sec-
onds. There may be a malfunction in a
system if the lights do not come on, or
turn off. Have the vehicle inspected by
your Lexus dealer.

*2

: This light comes on when the system is

turned off.

*3

: This light illuminates on the outside rear

view mirrors.

*4

: In order to confirm operation, the BSM

outside rear view mirror indicators illu-
minate in the following situations:

• When the engine switch is turned to

IGNITION ON mode while the
BSM main switch is turned on.

• When the BSM main switch is

turned on while the engine switch is
in IGNITION ON mode.

If the system is functioning correctly, the
BSM outside rear view mirror indicators
will turn off after a few seconds. If the BSM

(Canada)

Parking brake indicator
(



P.139)

Brake hold standby indicator

*1

(



P.142)

Brake hold operated indicator

*1

(



P.142)

Eco Driving Indicator Light

*1

(



P.79)

Snow mode indicator (



P.136)

Low outside temperature indi-
cator

*6

 (



P.69)

Security indicator

*7

 (



P.60,

61)

(U.S.A.)

“AIR BAG ON/OFF”
indicator

*1, 7

 (



P.36)

(Canada)

“AIR BAG ON/OFF”
indicator

*1, 7

 (



P.36)

Eco drive mode indicator
(



P.227)

Custom mode indicator (if
equipped) (



P.227)

Sport mode indicator (if
equipped) (



P.227)

SPORT S mode indicator (if
equipped) (



P.227)

Sport S+ mode indicator (if
equipped) (



P.227)

Custom mode indicator (if
equipped) (



P.227)

Eco drive mode indicator
(



P.227)

Sport mode indicator (if
equipped) (



P.227)

Sport S mode indicator (if
equipped) (



P.227)

Sport S+ mode indicator (if
equipped) (



P.227)
