2-1. Instrument cluster

2

Vehi

cle

 status

inform

ati

on a

nd i

ndic
ators



Main meter in center position (IS500)

The units of measure may differ depending on the intended destination of the vehicle.

Engine oil temperature gauge

Displays the engine oil temperature

Outside temperature

Displays the outside temperature within the range of -40°F (-40°C) to 122°F (50°C)

Tachometer

Displays the engine speed in revolutions per minute
When sport mode is selected for the driving mode, the periphery of the tachometer will
change color and the scale of the tachometer will be emphasized.

Speedometer
Shift position and gear position (



P.134)

Clock

Time displayed is linked to the analog clock on the center panel. (



P.260)

Engine coolant temperature gauge

Displays the engine coolant temperature

Odometer and trip meter display (



P.74)

Fuel gauge

Displays the quantity of fuel remaining in the tank

Multi-information display

Presents the driver with a variety of vehicle data (



P.75)

Displays warning messages if a malfunction occurs (



P.338)

A

B

C

D

E
F

G

H

I

J
