Vehicle Care

263

The vehicle may not be equipped with all of
the fuses, relays, and features shown.

Fuses

Usage

F1

TCM BATT

–

Traction Control

Module Power

F2

ECM BATT

–

Engine Control

Module Power

F3

A/C CLTCH

–

Air Conditioning

Clutch

F4

–

F5

4 CYL Engine

–

ECM/FPPM

RUN/CRANK

–

Engine Control

Module Run/Crank

–

Fuel

Pump Power Module Run
Crank

6 CYL Engine

–

ECM/ICCM/

FPPM RUN/CRANK

–

Integrated Chassis Control
Module Run/Crank

–

Engine

Control Module Run/Crank

–

Fuel Pump Power Module Run
Crank

F6

WIPER

–

Front Wipers

F7

Cargo Lamp/Bed Lighting

Fuses

Usage

F8

4 CYL Engine

–

Spare

6 CYL Engine

–

INJ EVEN

–

Fuel Injectors Even

F9

4 CYL Engine

–

Injectors

6 CYL Engine

–

INJ ODD

–

Fuel

Injectors Odd

F10

ECM IGN

–

Engine Control

Module Ignition

F11

MISC 1

–

Oxygen/Mass Air

Flow/Humidity/Induction Air
Temperature/Throttle Inlet
Pressure Sensors

F12

Starter

F13

TCM RUN/CRNK

–

Traction

Control Module Run/Crank

F14

–

F15

–

F16

–

F17

FRT AXLE ACT

–

Front Axle

Actuator

F18

–

F19

AERO SHTR

–

Aeroshutters

Fuses

Usage

F20

–

F21

FRT BLWR

–

Front Blower

F22

ABS VLV

–

Antilock Brake

System Valves

F23

–

F24

TRLR

–

Trailer

F25

TREC

–

Transfer Case

Electronic Control

F26

ABS PUMP

–

Antilock Brake

System Pump

F27

TRLR BRK CNTRL MDL

–

Trailer

Brake Control Module

F28

REAR WNDW DEFOG - Rear
Window Defogger

F29

–

F30

HTD SEAT DVR

–

Driver

Heated Seat

F31

–

F32

HTD SEAT PASS

–

Passenger

Heated Seat
