INSTRUMENT PANEL

02010200-129-555AB1

Instrument Panel

1 — Turn Signal/High Beams Lever

4 — Hazard Warning Lights Button

7 — Driver Air Bag

2 — Instrument Cluster

5 — Passenger Air Bag

3 — Windshield Wiper And Washers

6 — Ignition Switch

11
