INTERNAL EQUIPMENT; Operating The System; Reprogramming The- Page 69

Note:

To program the remaining two

HomeLink buttons, begin with step
one.
For questions or comments, please
contact HomeLink at

www.homelink.com

or

1-800-355-3515

.

Gate Operator/Canadian
Programming

Canadian radio-frequency laws require
transmitter signals to “time-out” (or quit)
after several seconds of transmission -
which may not be long enough for
HomeLink to pick up the signal during
programming.
Similar to this Canadian law, some U.S.
gate operators are designed to
“time-out” in the same manner.
If you live in Canada or you are having
difficulties programming a gate operator
by using the “Programming”
procedures (regardless of where you
live), replace “Programming The
System” step three with the following:

Note:

If programming a garage door

opener or gate operator, it is advised to
unplug the device during the “cycling”
process to prevent possible
overheating.
1. Continue to press and hold the
HomeLink button while you

press and

release

-

every two seconds

(“cycle”)

your hand-held transmitter until the
frequency signal has successfully been

accepted by HomeLink (the indicator
light will flash slowly and then rapidly).
2. Proceed with the “Programming”
steps to complete.

Operating The System

Push the programmed HomeLink
button to operate a programmed
device.
The code will continue being
transmitted for a maximum of
20 seconds.

Reprogramming The
System

To program a device to HomeLink using
a HomeLink button previously trained,
follow these steps:
1. Push and hold the desired HomeLink
button.

DO NOT

release the button;

2. The indicator light will begin to flash
after 20 seconds. Without releasing the
HomeLink button, proceed with
“Programming The System” step one.

Erasing Programmed
HomeLink Buttons

To erase the existing programming from
all three operating channels, push and
hold the two outside buttons 1 and
3 on the auto-dimming mirror until the
HomeLink indicator light begins to flash
after approximately ten seconds.
Verify that the programming has been
erased when you resell the vehicle.

INTERNAL
EQUIPMENT

Storage Compartments

Center Console

The center console is located between
the driver’s and passenger’s seats.

Warning!

Keep storage compartments closed
when driving. Driving with the storage
compartments open is dangerous.
To reduce the possibility of injury in an
accident or a sudden stop, keep the
storage compartments closed when
driving.

Caution!

Do not leave lighters or eyeglasses in the
storage compartments while parked under
the sun. A lighter could explode or the
plastic material in eyeglasses could deform
and crack from high temperature.

67
