INTERIOR OVERVIEW

0204139935US

Interior Overview

1 — Instrument Cluster

4 — Climate Control System

7 — Seats

2 — Steering Wheel

5 — Transmission Gear Selector

8 — Radio Controls

3 — Radio Systems

6 — Parking Brake

12
