ENGINE COMPARTMENT

Checking Levels

07030300-121-003

1 — Window Washer Reservoir

4 — Engine Coolant Reservoir

2 — Engine Oil Dipstick

5 — Brake/Clutch Fluid Reservoir

3 — Engine Oil Cap

6 — Battery

235
