Airflow Mode

06010202-121-0021

Airflow Locations

1 — Fixed Upper Air Diffuser
2 — Adjustable Side Air Vents
3 — Adjustable Center Air Vent
4 — Floor Vents

46

GETTING

TO

KNOW

YOUR

VEHICLE
